Product Overview

Analog Soul, Digital Precision

The 500ADAT acts as a bridge between your digital audio interface and the world of 500 series hardware. By using standard ADAT optical cables, it adds 8 channels of high-end analog I/O to your setup without the clutter of multicore cables. It features the same elite-level clocking and conversion as the flagship 500R8, ensuring that the "mojo" of your analog modules is captured with 121dB of dynamic range and ultra-low jitter.

Product Description

High-Performance Conversion & ADAT Expansion:

The 500ADAT provides 8 channels of recording and playback via ADAT. It supports SMUX II/IV, allowing for high-resolution audio expansion:

• 44.1/48kHz: 8 channels of I/O.

• 88.2/96kHz: 8 channels of I/O.

• 176.4/192kHz: 4 channels of I/O.

  Every stage of the signal path is designed for transparency, using a master reference-quality internal clock (<0.5ps jitter) to eliminate digital artifacts.

Advanced Summing and Monitoring:

• 8-into-2 Analog Summing: Located after the 500 series slots, this high-headroom mixer (+26.5dBu) lets you sum DAW stems through your analog hardware. Use the dedicated level and pan controls on the front panel to create a stereo mix with authentic analog "glue."

• Zero-Latency Artist Mixer: Create professional monitor mixes for musicians by blending live analog inputs with DAW playback.

• Dual Reference Headphone Amps: Two independent outputs with enough power to drive even high-impedance headphones with a linear frequency response down to 1Hz.

Versatile Routing & C.A.S.T.:

The Cranborne Audio 500ADAT features Source Select switches for each slot, allowing you to instantly toggle between Analog, ADAT, or C.A.S.T. inputs. The proprietary C.A.S.T. system enables you to send and receive 4 channels of balanced audio over a single Cat 5e/6/7 cable, perfect for connecting breakout boxes in vocal booths or other rooms.

Key Features

• 8-Slot 500 Series Rack: High-current supply providing 250mA per slot.

• ADAT Expander: 8-in/8-out digital expansion for any ADAT-ready interface.

• 121dB Dynamic Range: Boutique-grade A/D-D/A conversion.

• Discrete Summing Mixer: Analog 8-into-2 summing with per-slot Pan and Level.

• C.A.S.T. I/O: Simplified studio cabling via shielded Cat 5.

• Chain Switch: Internally route the output of one module into the next.

• Slot Bypass: Use the internal converters even if a slot is empty.

• Precision Clocking: BNC Word Clock I/O for system-wide synchronization.

Technical Specifications

What’s Included in the Box

• 1 x Cranborne Audio 500ADAT Unit

• 1 x 24V 5A External Locking Power Supply

• 1 x IEC Power Cable

• 16 x Module Fixing Screws

• 1 x 2.5mm Allen Key
