Neumann 008571 Capsule for KM A/D KK 185 nx Modular small diaphragm capsule with analog output stage
Home / Neumann 008571 Capsule for KM A/D KK 185 nx Modular small diaphragm capsule with analog output stage
Product Overview
The Neumann KK 185 nx represents the pinnacle of directional control within the KM A/D modular small-diaphragm system. This passive pressure gradient transducer is engineered to provide significantly higher directivity than a standard cardioid, effectively suppressing unwanted ambient noise. The "nx" version is coated in specialized Nextel matte black, a scratch-resistant and glare-free finish that is the industry standard for television, film sets, and prestigious live theater.
Product Description
Surgical Focus for Demanding Environments:
The KK 185 nx is specifically designed to excel where isolation is a challenge. Its hypercardioid polar pattern provides approximately 10 dB of attenuation for sound incident from the sides and rear, with the point of minimum sensitivity (the "null") occurring at 120°. This allows engineers to effectively "aim" the rejection at unwanted sound sources—such as a hi-hat near a snare or a neighboring instrument in a crowded orchestral pit—while maintaining a clear, direct signal.
The "nx" Professional Advantage:
In modern broadcast and cinematic production, equipment must not distract the viewer. The Nextel Black finish of the KK 185 nx ensures that the capsule does not catch light reflections or glints, even under high-intensity LEDs or stage spots. Combined with the modular system's tiny footprint, this capsule provides a sleek and unobtrusive profile that blends into any high-end set.
Modular Flexibility (Analog & Digital):
As a passive capsule head, the KK 185 nx is fully compatible with both the KM A nx (Analog P48) and KM D nx (Digital AES 42) output stages. This modularity means you can switch between a traditional analog signal path and a high-resolution digital workflow without changing your microphone heads. For remote applications, the capsule can be detached and used at distances of up to 100 meters via specialized extension cables (like the LC 4), making it ideal for overhead booms or hidden plant mics.
Legendary Acoustic Linearity:
Despite its tight directivity, the KK 185 nx maintains a remarkably natural and uncolored sound. The frequency response is smooth and linear, with a subtle treble boost around 10 kHz that adds a professional sense of "air" and definition. With a maximum SPL handling of 152 dB (using the -10 dB pad on the KM A output stage), it captures everything from the quietest string passages to the most explosive percussion with absolute fidelity.
Key Features
Nextel Black (nx) Finish: Professional non-reflective matte coating for film, TV, and stage.
Hypercardioid Polar Pattern: Extreme isolation and high gain-before-feedback.
Modular Compatibility: Threads directly onto KM A (Analog) and KM D (Digital) output stages.
152 dB Max SPL: Distortion-free performance even on the loudest sound sources.
Frequency-Independent Rejection: Maintains tonal accuracy even for off-axis sound.
German Engineering: Hand-assembled to the highest tolerances for perfect multi-mic matching.
Applications
Drums & Percussion: Perfect for snare and toms to minimize cymbal spill.
Acoustic Instruments: Ideal for guitar, violin, or winds in loud, high-pressure ensembles.
Film & TV Dialogue: High directivity helps capture clear speech in reverberant rooms.
Orchestral Spot-Miking: Provides the separation needed to highlight soloists within a full orchestra.
